|Monitor:||3.5" HD Monitor||Waterproof:||Camera/Object Glass/Tubes:IP67|
|Power:||Consumption 2W||Working Time:||≥8 Hours|
|Camera:||Megapixel Camera||Data I/O Port:||Micro-USB Port,HDMI Port|
non destructive testing machine,
portable surface roughness tester
Megapixel Camera Front View Industrial Borescope with Depth of Field 150mm for Visual Inspection
What is Borescope?
A borescope is an optical device which can be used for visual inspection of inaccessible work areas. This device consists of a rigid or flexible tube, with an eyepiece on end. It is also surrounded by the optical fibres, which helps the user to illuminate the remote object inaccessible by other means. The objective lens and the eyepiece help to magnify the internal image by illuminating.
There are two types of borescopes available in the market. One is rigid, and the other one is flexible. An imaging or video device is set with the borescope. Where accessibility is destructive, time-consuming, or expensive, one should try borescope. When the same type of device with similar functionality use inside a human body, it is called Endoscope.
Depth of Field:
With regards to a borescope, fiberscope, videoscope or pipe camera the depth of field or focal distance is the distance, measured from the objective tip of the instrument at which a usable image is available.
Typically, expressed with a minimum and a maximum distance, i.e. 3 to 9mm. In this example if the tip of the instrument were closer than 2mm the image will become blurry and if further than 9 it will become too grainy to be of use.
iqualitrol videoscopes are widely used in the fields of automotive manufacturing, car aftermarket, police security checking, aviation and aerospace area, special inspection institute, pharmaceutical machinery, non-destructive testing explosion-proof detection, ect.
Automotive, Quality control examination of engines, hydraulic components, injection nozzles, as well as final inspection of assembles;
Defense/security, Maintenance of military aircraft, as well as for detection of narcotics and other contraband items, and search of victims who may be trapped as the result of various disasters;
Architecture/Construction, Examination of walls, ducts, structural joints of bridges and constructions;
All products are complied with RoHS, CE and ISO standard and passed testing for temperature, waterproof, drop, vibration and pressure. Our vision is providing high-quality professional inspection instrument to every customer.
|Host System Working Temperature||-20°C~50°C, when 0°C below, the display needs preheating.|
|Camera Working Temperature||-20°C~80°C, when 0°C below, please reduce oriented operation.|
|Relative Humidity||Maximum: 92%, non-condensing|
|View Direction||Model||Main Specifications|
|Automotive Videoscope||iTA-6010||Tube Diameter 6mm；One mega pixels；Tube Length 1.0 meter；360° articulation；3.5'' display|
|iT35H 6mm Front view||iT35H-6015||Tube Diameter 6mm；One mega pixels；Tube Length 1.5 meter；360° articulation；3.5'' display|
|iT35H-6020||Tube Diameter 6mm；One mega pixels；Tube Length 2.0 meters；360° articulation；3.5'' display|
|iT35H 6mm Side view||iT35H-6015S||Tube Diameter 6mm；One mega pixels；Tube Length 1.5 meters；360° articulation；3.5'' display|
|iT35H-6020S||Tube Diameter 6mm；One mega pixels；Tube Length 2.0 meters；360° articulation；3.5'' display|
|iT35H 6mm Dual Lens||iT35H-6015D||Tube Diameter 6mm；One mega pixels；Tube Length 1.5 meters；360° articulation；3.5'' display|
|iT35H-6020D||Tube Diameter 6mm；One mega pixels；Tube Length 2.0 meters；360° articulation；3.5'' display|
|iT35H-3810||Tube Diameter 3.8mm；One mega pixels；Tube Length 1.0 meters；360° articulation；3.5'' display|
|iT35H-3815||Tube Diameter 3.8mm；One mega pixels；Tube Length 1.5 meters；360° articulation；3.5'' display|
|Camera Material||Titanium alloy|
|Camera Pixel||Mega Pixel|
|Depth of Field||20mm～150mm/ 10-100mm|
|Angle of Field||120°|
|Illumination||30,000lx at a maximum|
|Bright/Chroma/Contrast Ratio Adjustment||Manual, bright: six levels, chroma and contrast ratio: manual adjusting|
|Articulation||360° all-way articulation|
|Effective Working Length||2m|
Protecting Device of
|Buffer protection device between the host and wear-resistant tube|
|Display||Highlight 3.5 inches TFT LCD, can be replaceable for 5.7 inches display|
|IR Function||IR/IR thermal imaging(optional)|
|Memory||Standard TF card:8G, Maximum: 32G|
|Language||Chinese, English, Russian… 8 languages|
|Data I/O port||Micro-USB port,HDMI port|
|Working Time||≥8 hours|
|Power Supply||Rechargeable lithium battery(or built-in battery)|
|Battery Capacity||3.7V 3200mAh|
|Charging Parameters||DC5V, Maximum current:1A|
