Automotive Video Borescope Camera LCD Handheld Digital Endoscope

China Automotive Video Borescope Camera LCD Handheld Digital Endoscope supplier
Automotive Video Borescope Camera LCD Handheld Digital Endoscope supplier Automotive Video Borescope Camera LCD Handheld Digital Endoscope supplier Automotive Video Borescope Camera LCD Handheld Digital Endoscope supplier Automotive Video Borescope Camera LCD Handheld Digital Endoscope supplier

Large Image :  Automotive Video Borescope Camera LCD Handheld Digital Endoscope

Product Details:

Place of Origin: DONGGUAN
Brand Name: iqualitrol
Certification: CE
Model Number: i35-6050HF

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Carton box
Delivery Time: 3 Working Days
Payment Terms: T/T
Supply Ability: 100 sets per month
Detailed Product Description
Depth Of Field: 10-100mm (optional 7-110mm) View: Megapixel Camera Front View
Replaceable: Tubes Diameter From 2mm To 6mm Application: Engines, Hydraulic Components, Injection Nozzles
Monitor: 3.5" And Optional 5.7" Monitor IR Function: IR/IR Thermal Imaging (optional)
High Light:

Automotive Video Borescope

,

Video Borescope Camera

,

LCD Handheld Digital Endoscope


Automotive Video Endoscope Inspection of Engines Injection Nozzles All‐way Articulation



Difference Between Borescope and Endoscope



As now we know that the endoscope is a type of borescope and both have very similar functionality, most people believe that there is no difference between these two products. But, it is not entirely correct. Although the devices look identical with some matching features, they are different than each other.

Endoscopes’ outer diameter is thinner than the borescopes’ diameters.



The endoscope allows an effortless glide, while borescope varies to correspond with the running projects.

An endoscope is more flexible than the borescope because of its necessity of wiggle room. Both devices are available in flexible as well as rigid forms though.



If magnification is your primary purpose, then you should definitely go for some endoscope. Borescopes can also provide the same, but with the higher prices.



Endoscopes tend to have dimmer lights than the borescopes. Dimmer lights are more preferable to accommodate the internal structure of the human body.



There is a significant difference when there is a discussion about the direction of view. Borescope can reach up to 120 degrees, while the endoscope is limited to the 90 degrees only. It often has a built-in direction view, which you can adjust.



There are also some length differences which depends on customer’s choice. One can get both of these instruments in the same size, but people prefer small length endoscopes and all size of borescopes.



As borescope can be rigid as well as flexible, people prefer it more for their household works. A rigid borescope is inexpensive, easy to use, and also give higher quality images. On the other hand, flexible instrument lets you see inside. Blue flexible borescopes also offer the additional benefit of articulation – the ability to remotely control the tip of the device so that it bends in different directions to look around a cavity or issues.



Model Selection iqualitrol Automotive Videoscope:

View Direction Model Main Specifications
Automotive Videoscope iTA-6010 Tube Diameter 6mm;One mega pixels;Tube Length 1.0 meter;360° articulation;3.5'' display
iT35H 6mm Front view iT35H-6015 Tube Diameter 6mm;One mega pixels;Tube Length 1.5 meter;360° articulation;3.5'' display
iT35H-6020 Tube Diameter 6mm;One mega pixels;Tube Length 2.0 meters;360° articulation;3.5'' display
iT35H 6mm Side view iT35H-6015S Tube Diameter 6mm;One mega pixels;Tube Length 1.5 meters;360° articulation;3.5'' display
iT35H-6020S Tube Diameter 6mm;One mega pixels;Tube Length 2.0 meters;360° articulation;3.5'' display
iT35H 6mm Dual Lens iT35H-6015D Tube Diameter 6mm;One mega pixels;Tube Length 1.5 meters;360° articulation;3.5'' display
iT35H-6020D Tube Diameter 6mm;One mega pixels;Tube Length 2.0 meters;360° articulation;3.5'' display
iT35H
3.8mm
iT35H-3810 Tube Diameter 3.8mm;One mega pixels;Tube Length 1.0 meters;360° articulation;3.5'' display
iT35H-3815 Tube Diameter 3.8mm;One mega pixels;Tube Length 1.5 meters;360° articulation;3.5'' display




   Automotive Video Borescope Camera LCD Handheld Digital Endoscope 0



The similarity of Borescope and Endoscope

The stuff stated above is some real difference of endoscope vs borescope. You will be pleased to know that you can always choose any of them, whether borescope or endoscope according to your choice, budget, and purpose of use, as both are trending nowadays and high in demand because of their extraordinary abilities of visual detection.



They both are movable, adjustable, easy to use, and very helpful to reach through some cracks or inaccessible area. I hope this article will be beneficial to you.


Application:

iqualitrol videoscopes are widely used in the fields of automotive manufacturing, car aftermarket, police security checking, aviation and aerospace area, special inspection institute, pharmaceutical machinery, non-destructive testing explosion-proof detection, ect.



Aerospace:

airframe examinations, inspection of turbine blades and combustion chambers, and research, development and production of rocket engines.



Power Generation

Maintenance of heat exchanger pipes, condensers, piping and turbines in nuclear and thermal power Generation plants, and gearboxes of wind power generation facilities.



Oil/gas/chemical plants

Routine and urgent inspection of process piping, pressured storage reservoirs, heat exchangers, boilers, etc.



Automotive:

Quality control examination of engines, hydraulic components, injection nozzles, as well as final inspection of assembles;



Defense/security

Maintenance of military aircraft, as well as for detection of narcotics and other contraband items, and search of victims who may be trapped as the result of various disasters;



   Automotive Video Borescope Camera LCD Handheld Digital Endoscope 1


Operation Environment:

Host Working Temperature -20°C~50°C, when 0°C below, the display needs preheating.
Camera Working Temperature -20°C~80°C, when 0°C below, please reduce oriented operation.
Store Temperature -23°C~63°C
Relative Humidity Maximum: 92%, non-condensing


Technical Specifications:

Camera Diameter(mm) Φ6mm
Camera Material Titanium alloy
Camera Pixel Mega Pixel
Depth of Field 20mm~150mm/ 10-100mm
Angle of Field 120°
Illumination 30,000lx at a maximum
Bright/Chroma/Contrast Ratio Adjustment Manual, bright: six levels, chroma and contrast ratio: manual adjusting
Articulation 360° all-way articulation
Bending Angle ≥180°
Effective Working Length 2m
Insert Tube tungsten-braided

Protecting Device of
Durability

Buffer protection device between the host and wear-resistant tube
Display Highlight 3.5 inches TFT LCD, can be replaceable for 5.7 inches display
Display Resolution 1280*720
Image Resolution 1280*720
Video Resolution 1280*720
Image/Video Format JPEG/MOV
WIFI Function WIFI(optional)
IR Function IR/IR thermal imaging(optional)
Memory Standard TF card:8G, Maximum: 32G
Language Chinese, English, Russian… 8 languages
Data I/O port Micro-USB port,HDMI port
Waterproof Camera/Object glass/Tubes:IP67
Working Time ≥8 hours
Weight ≤0.55kg(with batteries)
Power Supply Rechargeable lithium battery(or built-in battery)
Battery Capacity 3.7V 3200mAh
Power Consumption 2W
Charging Parameters DC5V, Maximum current:1A
