Salt Spray Test Chamber with Precision Temperature Controller for Long Time Running

China Salt Spray Test Chamber with Precision Temperature Controller for Long Time Running supplier
Salt Spray Test Chamber with Precision Temperature Controller for Long Time Running supplier Salt Spray Test Chamber with Precision Temperature Controller for Long Time Running supplier Salt Spray Test Chamber with Precision Temperature Controller for Long Time Running supplier Salt Spray Test Chamber with Precision Temperature Controller for Long Time Running supplier

Large Image :  Salt Spray Test Chamber with Precision Temperature Controller for Long Time Running

Product Details:

Place of Origin: Dongguan/China
Brand Name: iqualitrol
Certification: CE
Model Number: AHL-60

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Box
Delivery Time: 20 Working Days
Payment Terms: T/T, Western Union
Supply Ability: 20 Sets per Month
Contact Now
Detailed Product Description
Temperature: NSS ACSS 35℃±1℃ / CASS 50℃±1℃ Solution: Solution Consistence NaCl 5%
Spray Quantum: 1.0~2.0(ml/80cm2/h) Heater: Corrosion-Resistant Titanium Tube
High Light:

salt spray corrosion test chamber

,

salt spray test machin


Salt Spray Test Chamber With Precision Controller Salt Spray Corrosion Test Chamber

Brief Introduction:
Salt Spray Test Chambers offer the most realistic and dependable corrosion test, widely used to test corrosion resistance of automotive, paint, surface coating, chemical, aerospace, electronic, car industry, offshore and defense industries.

Specifications:

Please note: AHL-60 and AHL-90 do not meet standard of ASTM B117.

ModelAHL-60AHL-90AHL-120AHL-160AHL-200

Interior
dimensions
(mm)

W600900120016002000
D45060085010001200
H400500500550600

Exterior dimensions
(mm)

W11301460220026003000
D630910120014501650
H10701280145015501600
Chamber Volume108 L270 L480 L800 L1440 L
Solution Tank15L25 L40 L
Power SupplyAC 220V 50HZAC 380V 50HZ
Ambient temp. & humid. range+5℃ ~ +35℃ / <85%RH
Testing TemperatureNSS ACSS 35℃±1℃ / CASS 50℃±1℃
Air TemperatureNSS ACSS 47℃±1℃ /CASS 63℃±1℃
Solution ConsistenceNaCl 5%
PH ValueNASS ACSS:6.5~7.2 / CASS:3.0~3.2
Temperature fluctuation≦±0.5℃
Temperature uniformity≦2. 0℃
Temperature deviation≦±2.0℃
Spray quantum1.0~2.0(ml/80cm2/h)
Chamber Materialpolyvinyl chloride (PVC)
HeaterCorrosion-resistant titanium tube
Temperature sensorPlatinum Resistance (PT-100)
Safety deviceOver-temperature protection , leakage protection

Note:
1. The above specifications are for reference only, the actual specifications for the main quotation.
2. Custom made is available according to customers’ special requirements.

Features:
1, Chamber material is made of P.V.C Sheet, sturdily and will not be out of shape.
2, Test chamber is heated from five directions to ensure the temperature is uniformity distributed.
3, Spray nozzle is specially made, enable to spray the salt water with considerable speed, then falls on the surface of samples.
4, Hot and moist air keeps the humidity in the test chamber conforms testing request.
5, High precision P.I.D. temperature controller limits the temperature difference within the range of ±0.1℃.


Salt Spray Test Chamber with Precision Temperature Controller for Long Time Running
