| Tube: | Dia. 6mm, Opt. 3.9mm, 2.8mm | IR Function: | IR Thermal Imaging (optional) |
|---|---|---|---|
| Application: | Bores, Pipes, Holes And Cavities | Waterproof: | Camera/Object Glass/Tubes: IP67 |
| Image: | Resolution 1280*720 | Memory: | Standard TF Card:8G |
| High Light: | Infrared Industrial Video Borescope,Industrial Video Borescope 720P,Thermal Imaging Borescope |
||
720P Infrared Thermal Borescope with Tungsten Braided Tube Flexible Articulation Control
Brief Introduction:
iqualitrol borescope is an optical device which can be used for visual inspection of inaccessible work areas. This device consists of a rigid or flexible tube, with an eyepiece on end. It is also surrounded by the optical fibres, which helps the user to illuminate the remote object inaccessible by other means. The objective lens and the eyepiece help to magnify the internal image by illuminating.
There are two types of borescopes available in the market. One is rigid, and the other one is flexible. An imaging or video device is set with the borescope. Where accessibility is destructive, time-consuming, or expensive, one should try borescope. When the same type of device with similar functionality use inside a human body, it is called Endoscope.
Model Selection iqualitrol Automotive Videoscope:
| View Direction | Model | Main Specifications |
| Automotive Videoscope | iTA-6010 | Tube Diameter 6mm；One mega pixels；Tube Length 1.0 meter；360° articulation；3.5'' display |
| iT35H 6mm Front view | iT35H-6015 | Tube Diameter 6mm；One mega pixels；Tube Length 1.5 meter；360° articulation；3.5'' display |
| iT35H-6020 | Tube Diameter 6mm；One mega pixels；Tube Length 2.0 meters；360° articulation；3.5'' display | |
| iT35H 6mm Side view | iT35H-6015S | Tube Diameter 6mm；One mega pixels；Tube Length 1.5 meters；360° articulation；3.5'' display |
| iT35H-6020S | Tube Diameter 6mm；One mega pixels；Tube Length 2.0 meters；360° articulation；3.5'' display | |
| iT35H 6mm Dual Lens | iT35H-6015D | Tube Diameter 6mm；One mega pixels；Tube Length 1.5 meters；360° articulation；3.5'' display |
| iT35H-6020D | Tube Diameter 6mm；One mega pixels；Tube Length 2.0 meters；360° articulation；3.5'' display | |
| iT35H 3.8mm |
iT35H-3810 | Tube Diameter 3.8mm；One mega pixels；Tube Length 1.0 meters；360° articulation；3.5'' display |
| iT35H-3815 | Tube Diameter 3.8mm；One mega pixels；Tube Length 1.5 meters；360° articulation；3.5'' display |
Tube System:
| Probe Diameter | Φ2.2/Φ2.4/Φ2.8mm | Φ3.9/Φ6mm |
| Camera Pixels | 300,000 | 1,000,000 |
| Image Resolution | 640×480 | 1280×720 |
| Video Resolution | 640×480 | 1280×720 |
| DOF | 3 mm-50mm/5 mm-80mm | 10mm-100mm/5 mm-80mm/50 mm-∞ |
| Field Angle | 90°/120° | |
| Light Source | Front ceramic light/ Rear-mounted optic fiber cold | |
| Illuminance | Maximum: 100000+Lx 1~9 levels adjustable light | |
| Tube Length | 1.5m/3.0m/5.0m/30m (customized for other length) | |
| Protecting Device of Durability | 42mm buffer protection device between tube and handle | |
| Articulation | 360° all-way | |
| Bending Angle | Maximun:190° | |
| Probe Positioning | Damping positioning & articulation lock device | |
| Wi-Fi Transmission | Image transmission to Mobile phone, computer by Wi-Fi(optional) | |
Monitor System:
| Display | 3.5” or 5.1" color IPS display, all sight viewing angle, sunshade design |
| Display Resolution | 1280*960 |
| Zoom In/Out | 8X |
| Language | Chinese/English/Russian and other 8 languages |
| White Balance Suppression | 5 levels adjustable |
| White Balance | Auto white balance, automatically adjusts and eliminates speckles to achieve optimal images. |
| Image Effect | negative film/ black & white/standard |
| Temperature Indication | High temperature alarm |
| IP Level | Probe/tube: IP67 |
| Software Function | Playback, image parameters adjust and rotate |
| Structure | Hand-held integrated design |
| Image/video format | JPEG/MOV |
| Scale | The analog scale can be used to compare and analyze the internal defect and size of the inspected object. |
| Data Port | HDMI video output, Micro USB port with water &dust proof device |
| Working Time | ≥8h |
| Battery Capacity | 3.7V,3200mAh×2 |
| Power Charge | DC5V, 1A |
| Weight | ≤0.8Kg |
| Compatibility | Interchangeable monitor and tube with different diameters |
| Standard Configuration | Instrument case:1pc; videoscope: 1 set; battery: 2pcs; card reader: 1pc; 32G. TF card: 1pc; charger: 1pc; usb line: 1pc; user manual & certificate: 1 set |
Application:
Oil and gas platforms, refineries and compressor stations all appreciate the portability, durability and lightweight of iqualitrol video borescope. The high resolution image and powerful light output make inspecting the darkest and most remote location easy. Inspect pumps, turbines, rotating machinery, heat exchangers and more.
inspection of aircraft turbines. Airlines, military and aircraft engine manufacturers all rely on the superior resolution of iqualitrol video borescope to detect the smallest defect with ease.
