Water Cooling Programmable High Speed Automatic Hot Mounting Press with 4 Moulds

Water Cooling Programmable High Speed Automatic Hot Mounting Press with 4 Moulds
Water Cooling Programmable High Speed Automatic Hot Mounting Press with 4 Moulds Water Cooling Programmable High Speed Automatic Hot Mounting Press with 4 Moulds Water Cooling Programmable High Speed Automatic Hot Mounting Press with 4 Moulds Water Cooling Programmable High Speed Automatic Hot Mounting Press with 4 Moulds Water Cooling Programmable High Speed Automatic Hot Mounting Press with 4 Moulds

Large Image :  Water Cooling Programmable High Speed Automatic Hot Mounting Press with 4 Moulds

Product Details:
Place of Origin: Dongguan/China
Brand Name: iqualitrol
Certification: CE
Model Number: ZXQ-50S
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Case
Delivery Time: 3 Working Days
Payment Terms: T/T
Supply Ability: 30 Sets per Month
Detailed Product Description
Diameter: φ25mm, φ30mm, φ40mm, φ50mm Power: 1600W
Heating Range: 0~180℃ Dwell Time: 0~99 Minutes 99 Seconds
Net Weight: 104Kg Cooling Style: Water Cooling
High Light:

High Speed Metallographic Mounting Press

,

Metallographic Mounting Press AC220V



Water Cooling Programmable High Speed Automatic Hot Mounting Press with 4 Moulds



Model: ZXQ-50S



Technical Data Download: iqualitrol Mounting Press ZXQ-50S



Brief Introduction:

iqualitrol mounting press is used to handle small or odd shaped specimens and to protect fragile materials, thin layers or coating during preparation as well as to provide good edge retention.

Mounting produces specimens with uniform size so that it is easier to handle in automatic holders for further preparation steps.



In hot mounting, the specimen is mounted under heat and pressure with a hot mounting press.



Model iqualitrol ZXQ-50S is an automatic hot mounting press with water cooling function, suitable for almost materials. You only need to place the sample in the mould, select the program number for your specific application and depress the “Start” button. That’s it!



There are 4 moulds with different diameters, available to make two samples simultaneously.



Technical Specifications:

Moulds Diameter φ25mm, φ30mm, φ40mm, φ50mm
Power supply AC220V/50HZ/1Ph
Power Consumption 1600W
Heating Range 0~180℃
Dwell Time 0~99 Minutes 99 Seconds
Net Weight 104KG
Cooling Style Water Cooling
