Product Details:
Payment & Shipping Terms:
|
| Temperature: | Range -20℃ ~ +100℃ | Insulation: | Rigid Polyurethane Foam |
|---|---|---|---|
| Refrigerating: | Mechanical Cascade Refrigeration System | Refrigerant: | Refrigerant R404A |
| Compressor: | Air Cooling Hermetic Compressor | Heating System: | Stainless Steel Radiating Heater |
| Highlight: | temperature controlled chamber,temperature cycle chamber |
||
Programmable Thermal Humidity Alternating Climatic Test Chamber by Cold Balanced Control
Technical Data Download:
iqualitrol Vertical Programmable Temperature Test Chamber
Brief Introduction:
iqualitrol programmable temperature test chamber with wide range of temperature controls, mainly used to test performances of materials after in high temperature, low temperature, constant temperature or temperature alternating.
Temperature chamber is one of the essential test equipment for aerospace, automotive, home appliances, scientific research department, etc.
Temperature humidity test chamber is use to test material heat, cold, dry resistance, humidity resistance. Suitable for electronics, electrical appliances, communications, instrumentation, vehicles, plastic products, metal, food, chemical, building materials, medical, aerospace and other products.
Dimensions by Models:
| Model | Temp Range | Internal Dimension (W x H x D) cm |
Exterior Dimension (W x H x D) cm |
| QTL-V80B | -20℃～﹢150℃ | 40x50x40 | 60x110x95 |
| QTL-V150B | 50x60x50 | 70x120x105 | |
| QTL-V225B | 50x75x60 | 70x135x115 | |
| QTL-V416B | 70x85x70 | 90x145x125 | |
| QTL-V800B | 100x100x80 | 120x160x135 | |
| QTL-V1000B | 100x100x100 | 120x160x155 | |
| QTL-V80C | -40℃～﹢150℃ | 40x50x40 | 60x110x95 |
| QTL-V150C | 50x60x50 | 70x120x105 | |
| QTL-V225C | 50x75x60 | 70x135x115 | |
| QTL-V416C | 70x85x70 | 90x145x125 | |
| QTL-V800C | 100x100x80 | 120x160x135 | |
| QTL-V1000C | 100x100x100 | 120x160x155 | |
| QTL-V80D | -70℃～﹢150℃ | 40x50x40 | 60x110x95 |
| QTL-V150D | 50x60x50 | 70x120x105 | |
| QTL-V225D | 50x75x60 | 70x135x115 | |
| QTL-V416D | 70x85x70 | 90x145x125 | |
| QTL-V800D | 100x100x80 | 120x160x135 | |
| QTL-V1000D | 100x100x100 | 120x160x155 | |
| Remark: 20%～98%RH is standard humidity range, support custom made 10%～98%RH Or 5%～98%RH |
|||
| Support custom made dimension | |||
Technical Specifications:
| Control Mode | Cold Balanced Control System | |
| Operating Temp. & Humid. Range | +5℃ ~ +35℃; <85%R.H. | |
| Temp. Range | A=0℃, B=-20℃, C=-40℃, D=-70℃ ~ +100℃(150℃) | |
| Temp. Fluctuation | ±0.5℃ | |
| Temp. Uniformity | ≤2.0℃ | |
| Temp. Resolution | 0.01℃ | |
| Temp. Heating Time | -40℃ ~ +150℃within 35 min; -70℃ ~ +150℃within 60 min |
|
| Temp. Cooling Time | 20℃ ~ -40℃within 60 min; 20℃ ~ -70℃within 90 min |
|
| Power Supply | AC380V, 50/60HZ, Three-phase (Specified by User) | |
| Material | Exterior Material | Stainless steel with baking paint |
| Interior Material | SUS304# Stainless steel | |
| Insulation Material | Rigid polyurethane foam | |
| Refrigeration System | Refrigerating Method | Mechanical cascade refrigeration system |
| Compressor | Air cooling hermetic compressor | |
| Radiator | Fin type radiator | |
| Refrigerant | Refrigerant R404A | |
| Heating System | Stainless steel radiating heater | |
| Controller | Touch screen controller HL-1000 | |
| Safety Devices |
Overheat protector Switch Compressor overload protector switch Fault alarm system |
|
| Accessories |
Viewing window, Chamber lamp, Cable port ø50mm, Product shelf slides 2 pieces, universal casters, Touch screen controller HL-1000 |
|
Note:
1. The performance values are no specimen inside the test area
2. At 20℃ ambient temperature, rated voltage
3. According to IEC68-2-1 and IEC68-2-2
4. The above specifications are for reference only.
Products Conform Following Standards:
※ IEC60068-3-5-2002 Environmental testing-Part 3-5 Support documentation and guidance-Confirmation of the performance of temperature chambers
※ IEC68-2-1 (GB-2423.1-2008) Testing A: Low temperature testing method
※ IEC68-2-2 (GB-2423.2-2008) Testing B: High temperature testing method
※ MIL-STD-202F (GJB360.8-87) High temperature life testing
※ MIL-STD-810D (GBJ150.3) High temperature method
※ MIL-STD810D (GBJ150.4) Low temperature method
※ IEC68-2-3 (GB2423.3-93) Testing Ca: Constant moist heat testing method
※ IEC68-2-30 (GB2423.4-93) Testing Db: Alternate moist heat testing method
※ MIL-STD-810D (GJB150.9-93) Moist heat testing method
Features:
※ Heating/Cooling System: Completely independent heating/cooling system can improve testing efficiency and using life.
※ Cycle System: Powerful blowing cycle system to avoid blind angle, makes temperature and humidity evenly distributed in the test area.
※ Viewing window and interior light makes viewing workspace freely and observe the test under best conditions.
※ Touch screen controller HL-1000 is designed to save chamber programming and setup time with temperature limit and alarm to protect your product.
※ Safety relay connection is provided to protect your device under test by removing power to it when the chamber is not running.
※ RS-232 communications is for computer connection, programming can be set on computer by software, monitor testing process and automatically execute power on/off functions.
※ Chamber exterior material is stainless steel with environmentally baking paint resists corrosion and provides impact resistance. Interior material is SUS304# stainless steel with excellent heat resistance and easy to clean.
※ Adjustable product shelf slides out for easier product access. Shelf design is non-tipping and supports large product loads.
※ Left side of chamber with diameter 50mm cable port for power-on test.
