Diamond Indenter Rockwell Hardness Testing Machine AC110V 60Hz With Emergency Stop

Diamond Indenter Rockwell Hardness Testing Machine AC110V 60Hz With Emergency Stop
Diamond Indenter Rockwell Hardness Testing Machine AC110V 60Hz With Emergency Stop

Large Image :  Diamond Indenter Rockwell Hardness Testing Machine AC110V 60Hz With Emergency Stop

Product Details:
Brand Name: iqualitrol
Model Number: HR-150DT
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Packaging Details: Plywood Box
Delivery Time: 10 Working Days
Payment Terms: T/T
Supply Ability: 10 Sets per Month
Contact Now
Detailed Product Description
Scales: HRC, HRA, HRB Vertical: Max Height 190mm
Horizontal: Max Throat 160mm Indication: 0.5HR Dial Gauge
Highlight:

Diamond Rockwell Hardness Testing Machine

,

Rockwell Hardness Testing Machine AC110V

,

Rockwell Superficial Hardness Tester



New Generation Motorized Loading Rockwell Hardness Testing Machine with Emergency Stop



Brief Introduction:

iqualitrol HR-150DT Motorized Rockwell hardness tester adopts the mechanism of automatic loading and unloading of the test force, the test force is regulated by the load-change hand wheel.



Operator can select the dwell time by using HR-150DT, besides setting zero to dial, there is no man-made error. The instrument has high sensitivity and stability.



Application Range:

Suitable for quenched steel, tempered steel, annealed steel, cold and hard casting, malleable cast iron, hard alloy steel, aluminum alloy, copper alloy, bearing steel etc.



Technical Specification:

Model HR-150DT
Initial Test Force 10kgf (98.07N)
Total Test Force 60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N)
Indenter Diamond Rockwell Indenter, ф1.588mmBall Indenter
Loading Method Automatic (Loading/Dwell/Unloading)
Hardness Reading Dial
Resolution 0.5HR
Dwell Time 2~60s
Max. Height of Specimen 190mm
Throat 160mm
Power Supply AC220V/50Hz/1Ph, AC110V/60Hz/1Ph
Execute Standard ISO 6508, ASTM E-18, JIS Z2245, GB/T 230.2
Dimension 520×215×700mm, Packing Dimension: 650×370×950mm
Weight Net Weight: 78kg, Gross Weight: 100kg



Packing List:

Name Qty Name Qty
Instrument Main Body 1 set Diamond Rockwell Indenter 1 pc
ф1.588mmBall Indenter 1 pc Middle Plane Test Table 1 pc
Large Plane Test Table 1 pc V-shaped Test Table 1 pc
Hardness Block 60~70 HRC 1 pc Hardness Block 20~30 HRC 1 pc
Hardness Block 80~100 HRB 1 pc Weight A, B, C 3 pcs
Power Cable 1 pc Fuse 2A 2 pcs
Level 1 pc Horizontal Regulating Screw 4 pcs
Screw Driver 1 pc Spanner 1 pc
Anti-dust Cover 1 pc Usage Instruction Manual 1 copy



Tag:

Digital Rockwell Hardness Tester,

Automatic Rockwell Hardness Tester,

Rockwell Hardness Tester Machine
