Product Details:
Payment & Shipping Terms:
|
| Friction Speed: | 30 Circles Per Minutes | Friction Hammer: | Load 200g |
|---|---|---|---|
| Auxiliary Load: | 300g | Hammer Size: | 45 * 50 Mm |
| Test Piece: | Size 22*3mm | Friction Distance: | 100mm |
| Highlight: | material testing instruments,material testing equipment |
||
Dyeing Colour Fastness Universal Tensile Testing Machine with
2 Stations and LCD Controller
Brief Introduction:
The iqualitrol dyeing fastness tester is attached to the surface of the friction hammer of the machine with a dry or moist white cotton cloth, and after a certain amount of heavy load and frequency, after rubbing the colored test piece, the dyeing friction fastness level is evaluated according to the gray mark. It can also be used as a friction test for organic solvents. With power-off memory function.
Technical Specifications:
| Friction speed | 30 circles per minutes |
| Friction hammer load | 200g |
| Auxiliary load | 300g |
| size of the friction hammer | 45 * 50 mm |
| Size of test piece | 22 * 3 cm |
| white cotton cloth | 5 * 5 cm |
| Friction area of white cotton cloth | about 1cm2 |
| friction distance | 100mm |
| Counter | LCD 0~999,999 |
| number of friction groups | 6set |
| Power supply | AC220V/50Hz |
| Net Weight | 60Kg |
| Dimension | 60*50*40cm |
Specification——Colour fastness testing machine for electric fabric dyeing
Application :The machine Mainly uses in dyeing textiles, flocking fabric( tufting strength tests), leatherette( crock test), paperboard, printing, ink, paint and other material rubbing abrasion resistance test ,control gray scale to assessment staining friction fastness Level.
JIS Standard Brief Introduction——Colour fastness testing machine for electric fabric dyeing
JIS test standard color dyeing fastness tester to rubbing is suitable for dyeing og fabrics-leather by rubbing the degree of discoloration, test method is based on the dry or wet white cotton cloth, wrapped in friction cone, then rubs caught in the trial stage of the test piece, you can access color fastness grade.
Test standards: JIS-L0801, 0823, 0849, 1006, 1084, K6328, P8236.
