Digital Display Low Loading Force Brinell Hardness Testing Machine With Manual Turret

Digital Display Low Loading Force Brinell Hardness Testing Machine With Manual Turret
Digital Display Low Loading Force Brinell Hardness Testing Machine With Manual Turret

Large Image :  Digital Display Low Loading Force Brinell Hardness Testing Machine With Manual Turret

Product Details:
Place of Origin: Dongguan/China
Brand Name: iqualitrol
Certification: CE, ISO
Model Number: HBS-62.5
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Box
Delivery Time: 3 Working Days
Payment Terms: T/T
Supply Ability: 100 Sets per Month
Detailed Product Description
Test Force: 1, 5, 10, 15.625, 30, 62.5kgf Turret: Manual Turret
Loading Control: Automatic (load/dwell/unload) Magnification: Total Magnification: 50X, 100X
Printing: Built-in Printer Specimen: Maximum Height 165mm
High Light:

165mm Brinell Hardness Testing Machine

,

Low Loading Force Brinell Hardness Tester

,

Manual Turret Brinell Hardness Tester



Digital display low load Brinell hardness tester with Manual Turret



Model: HBS-62.5



Technical Data Download: iqualitrol Brinell Hardness Tester HBS-62.5



Product description:

Iqualitrol HBS-62.5 digital display low load Brinell hardness tester has good reliability, operability and intuitiveness. Through the buttons input, you can choose different indenters and force value measurement, adjust the lightness, dwell time.



The display can show the indenter diameter, test force, measuring range, hardness value is simple and easy to check from table.

It is easy to use and has higher measurement accuracy due to the use of an iqualitrol rotary encoder.



HBS-62.5 uses a relatively low loading force, so it is especially suitable for softer metals. Such as pure aluminum, copper, lead, tin, zinc and other alloys, the hardness measured is accurate. Hardness has high measurement accuracy, so reproducibility and representativeness.



Main features and features:

1, 4 inch large screen LCD display, menu structure,

2, the test process is automated, easy to operate,



3, high-definition optical system Light source brightness can be adjusted in 20 levels,

4, with hardness value conversion function, hardness up and down tolerance judgment,



5, diagonal length D1 and D2 encoder input, reducing human error,

6, test results and data processing, can be output through the printer.



7. The shell is cast once, the structure is stable and not deformed, and it can work in a harsh environment;

8. The surface is treated with automobile paint, which has strong scratching ability and is still bright and new for many years;



Main use and scope of use:

1. Suitable for hardness test with large grain metal materials, which can reflect the comprehensive performance of materials;

2, cast iron, steel, non-ferrous metals, especially for softer metals, such as pure aluminum, lead, tin, etc.





Technical Parameters:

model HBS-62.5
Test force 1, 5, 10, 15.625, 30, 62.5kgf
display 5-digit hardness value, 4-digit diagonal length (D1, D2),
Dwell time 1~99 seconds
Loading control Automatic (load/dwell/unload)
Hardness conversion Rockwell, Surface Rockwell, Vickers
Measuring resolution 0. 25μm (subject to the objective lens selected)
Objectives Objective lens: Observe or measure 5X measurement 10X (special objective lens please customize)
Magnification Total magnification: 50X 100X
Data print Built-in printer
Specimen Maximum height 165mm
Throat depth 130mm
Test standards Accuracy meets GB231.2, ISO6506-2 and ASTM E10
Power supply AC220V±5%, 50~60Hz
Net weight About 45kg
