Touch Screen Digital Low Load Brinell Hardness Tester SHB-62.5 Close Loop Control

Large Image : Touch Screen Digital Low Load Brinell Hardness Tester SHB-62.5 Close Loop Control

Product Details:

Brand Name:	iqualitrol
Model Number:	SHB-62.5

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Packaging Details:	Plywood Box
Delivery Time:	10 Working Days
Payment Terms:	T/T
Supply Ability:	20 Sets per Month

Contact Now

Detailed Product Description

Control:	Close Loop Control, Sensor Loading	Height:	Max Specimen Height 200mm
Throat:	130mm	Magnification:	50X, 100X
Visual Measuring:	CCD Image Processing System Or Video Measuring Device	Database Function:	Can Save More Than 2000 Data
Highlight:	Close Loop Control Brinell Hardness Tester , 62.5kgf Brinell Hardness Tester , 200mm Brinell Hardness Testing Machine

Close loop Control Touch Screen Digital Low Load Brinell Hardness Tester

Technical Specifications:

Model	SHB-62.5
Range of Measurement	5-650HBW
Test Force	9.807, 24.52, 49.03, 61.29, 98.07, 153.2, 294.2, 31.125, 612.9N (1, 2.5, 5, 6.25, 10, 15.625, 30, 31.25, 62.5kgf)
Maximum Height of Specimen	200mm
Distance between Indenter Center and Wall	130mm
Objective	5X, 10X
Total magnification	50X, 100X
Hardness Resolution	0.1HBW
Power Supply	AC 220V,50Hz
Dimension	600330700mm
Weight	75kg
