| Model: | HBS-62.5, Manual Turret, Weight Loading Test Force | Data Process: | USB, RS232 Interface, Convenient For Process Data |
|---|---|---|---|
| Display: | Digital Micrometer Eyepiece, Touch Screen Displays Of Hardness Value, Easy To Operate | Storage Function: | With Database Storage Function, Test Data Is Stored Synchronously And Can Be Exported |
Weights Low Loading Digital Brinell Hardness Tester iqualitrol HBS-62.5 with Manual Turret
Main Features:
● Manual turret; weight loading test force system;
● Cast iron casing, solid structure, good rigidity, reliable, durable, high test efficiency;
● Adopt ARM high-speed processor, 5.6-inch LCD touch screen;
● Digital micrometer eyepiece, touch screen displays of hardness value, easy to operate;
● Dynamic display of the indenter during the test, real-time observation of the test status;
● The screen can display the test force, indentation length, dwell time, number of measurements, etc.;
● various hardness scales value conversion;
● The test process is automated, the operation is simple, and there is no human error;
● With database storage function, test data is stored synchronously and can be exported;
● Equipped with USB and RS232 interfaces, convenient for users to process data;
● Equipped with a built-in printer, which can directly print the test results;
● Optional HYHB300 Brinell image measurement system;
● The accuracy meets GB/T231.2, ISO6506-2 and American ASTM E10.
Technical Parameters:
| Model | HBS-62.5 |
| Brinell Range | 3.2-650HBW |
| Test force |
9.80,49,98.07,153.2,294.2,612.9(N) 1,5,10,15.625,30,62.5(kgf) |
| Display | 5-digit hardness value, 4-digit diagonal length (D1, D2), Hold time, number of tests, average, standard deviation, return |
| Test force retention time(s) | 1~99 |
| Loading control | Automatic (load/dwell/unload) |
| Conversion | Rockwell, Superficial Rockwell, Vickers |
| Minimum measurement unit | 0. 25μm(Subject to the choice of objective lens) |
| Total magnification | Objective: Observe or measure 5X, measurement 10X (support special objective), Total magnification: 50X, 100X |
| Illumination | Halogen light source |
| Data output | Built-in printer |
| Vertical Space | Maximum height 180mm |
| Indenter center to inner wall | 125mm |
| Executive standard | Accuracy meets GB231.2, ISO6506-2 and ASTM E10 |
| Power supply | AC220V±5%, 50~60Hz |
| Instrument weight | About 85kg |
| Optional accessories | XY table, CCD measurement system |
Application range:
● Determine the Brinell hardness of ferrous metals, non-ferrous metals and other materials;
● Determine the Brinell hardness of bearing alloy materials such as lead-based alloys, babbitt alloys, tin-bismuth alloys, etc.;
● Determine the Brinell hardness of certain non-metallic materials such as hard plastics and bakelite;
● Determine the Brinell hardness of smaller parts produced by casting, forging, rolling and other processes.
